Spesifikasjoner
Generelt
Sokkel
AM5
Formfaktor
ATX
Chipsæt
B650 (AMD 7000)
Kompatible processorer
AMD Ryzen™ 7000 Series Processors
WiFi
Nei
Antal RAM slots
4
RAM Teknologi
DDR5
RAM
Ram Bus Clock
Supports up to 6400+(OC)
Maks. RAM kapacitet
128 GB
Interface
Ekspansionsåbninger
1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode* Chipset:
1 x PCIe 4.0 x16 Slot (PCIE3), supports x2 mode*
2 x PCIe 4.0 x1 Slots (PCIE2 and PCIE4)*
1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
1 x PCIe 4.0 x16 Slot (PCIE3), supports x2 mode*
2 x PCIe 4.0 x1 Slots (PCIE2 and PCIE4)*
1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
Grænseflade (lagring)
1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s)
1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s)
1 x M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x2 (32 Gb/s)
4 x SATA3
1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s)
1 x M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x2 (32 Gb/s)
4 x SATA3
Interne interfaces
1 x SPI TPM Header
1 x Power LED and Speaker Header
1 x RGB LED Header
3 x Addressable LED Headers
1 x CPU Fan Connector (4-pin)
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)
4 x Chassis/Water Pump Fan Connectors
1 x Power LED and Speaker Header
1 x RGB LED Header
3 x Addressable LED Headers
1 x CPU Fan Connector (4-pin)
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)
4 x Chassis/Water Pump Fan Connectors
Interfaces
2 x Antenna Mounting Points
1 x HDMI Port
1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s) (ReDriver)
7 x USB 3.2 Gen1 Ports
4 x USB 2.0 Ports
1 x RJ-45 LAN Port
1 x BIOS Flashback Button
1 x HDMI Port
1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s) (ReDriver)
7 x USB 3.2 Gen1 Ports
4 x USB 2.0 Ports
1 x RJ-45 LAN Port
1 x BIOS Flashback Button
Strømkontakter
1 x 24 pin ATX Power Connector
2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
Misc.
Dybde
30
Bredde
24
Tilbehør
1 x User Manual
2 x SATA Data Cables
3 x Screws for M.2 Sockets
2 x SATA Data Cables
3 x Screws for M.2 Sockets
