Spesifikasjoner
Generelt
Sokkel
AM4
Formfaktor
M-ATX
Chipset
A520 (AMD 3-5000 series)
Kompatible processorer
AMD Ryzen™ 5000 Series/ 3rd Gen Ryzen
WiFi
Nei
Antall RAM slots
4
RAM-teknologi
DDR4
RAM
Ram Bus Clock
DDR4 4866(O.C)/4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)
/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory
/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory
Maks. RAM-kapasitet
128 GB
Interface
Ekspansionsåbninger
1x PCIe 3.0 x16 (x16 mode)
2x PCIe 3.0 x1
2x PCIe 3.0 x1
Grænseflade (lagring)
4x SATA 6Gb/s ports
1x M.2 slot
1x M.2 slot
Interne interfaces
1x CPU Fan connector
2x Chassis Fan connectors
1x USB 3.2 Gen
2x USB 2.0 connectors
1x M.2 Socket
1x SPI TPM header
4x SATA 6Gb/s connectors
1x S/PDIF out header
2x Chassis Fan connectors
1x USB 3.2 Gen
2x USB 2.0 connectors
1x M.2 Socket
1x SPI TPM header
4x SATA 6Gb/s connectors
1x S/PDIF out header
Interfaces
1x PS/2 keyboard/mouse combo port(s)
1x DVI-D
1x D-Sub
1x HDMI
1x LAN (RJ45) port(s)
4x USB 3.2 Gen 1 (blue) Type-A
2x USB 2.0
3x Audio jack(s)
1x DVI-D
1x D-Sub
1x HDMI
1x LAN (RJ45) port(s)
4x USB 3.2 Gen 1 (blue) Type-A
2x USB 2.0
3x Audio jack(s)
Strømkontakter
1 x 24-pin EATX Power connector(s)
1 x 8-pin EATX 12V Power connectors
1 x 8-pin EATX 12V Power connectors
Misc.
Dybde
24
Bredde
24
Tilbehør
User´s manual
I/O Shield
2x SATA 6Gb/s cable(s)
1x Supporting DVD
1x M.2 SSD screw package(s)
I/O Shield
2x SATA 6Gb/s cable(s)
1x Supporting DVD
1x M.2 SSD screw package(s)
